Produk / T8 TWIN LAMPHOLDER – FTH 806 (PC)
T8 TWIN LAMPHOLDER – FTH 806 (PC)
The FTH 806 T8 Twin Lampholder (PC) is designed to securely hold two T8 fluorescent or LED tubes. Made from durable polycarbonate, it ensures reliable performance and easy installation, making it ideal for dual-tube lighting applications.
Kategori :
IP 20, Durable Lampholder, IP Rating, SIRIM, ST
Aplikasi :
T8 Light Fittings
Warna :
-
White
Body
Polycarbonate (PC)
Rotor
Polybutylene terephthalate (PBT)
Contact
Phosphor Bronze
Finishing
Smooth Finished Housing
Suitable Lamps
T8 Fluorescent Tube, T8 LED Tube
Model
FTH 806-S (PC)
Main Supply (V, Hz)
220~240V, 50/60Hz
Base Lamp
G13 (T8)
Base Starter
N/A
Rated Current
2A
Operating Temperature (ta)
120°
Wiring Type & Cross Section
0.5-1.0mm² (Strip 8 to 11.5mm)
Model
FTH 806-E (PC)
Main Supply (V, Hz)
220~240V, 50/60Hz
Base Lamp
G13 (T8)
Base Starter
N/A
IP Grade
IP 20
Rated Current (A)
2A
Operating Temperature (ta)
120°
Wiring Type & Cross Section
0.5-1.0mm² (Strip 8 to 11.5mm)
Model
FTH 806 (PC)
Main Supply (V, Hz)
220~240V, 50/60Hz
Base Lamp
G13 (T8)
Base Starter
GZ12.9
Rated Current (A)
2A
Operating Temperature (ta)
120°
Wiring Type & Cross Section
0.5-1.0mm² (Strip 8 to 11.5mm)
| Model | Product Weight (Kg) | Carton Size (mm) | Gross Weight (Kg) | Quantity | ||
|---|---|---|---|---|---|---|
| L | W | H | ||||
| FTH 806-S (PC) | 0.014 Kg | 530 mm | 370 mm | 370 mm | 14.98 Kg | 1,000 pcs / Carton |
| FTH 806-E (PC) | 0.018 Kg | 530 mm | 370 mm | 370 mm | 19.68 Kg | 1,000 pcs / Carton |
| FTH 806 (PC) | 0.019 Kg | 530 mm | 370 mm | 370 mm | 19.93 Kg | 1,000 pcs / Carton |
| Model | Base | Dimension | ||
|---|---|---|---|---|
| L | W | H | ||
| FTH 806-S (PC) | G13 (T8) | 88.7 mm | 24.3 mm | 36.6 mm |
| FTH 806-E (PC) | G13 (T8) | 101 mm | 25.2 mm | 44.5 mm |
| FTH 806 (PC) | G13 (T8) | 101 mm | 25.2 mm | 44.5 mm |
