Produk / LED EXIT SIGN – WEATHERPROOF (IP65) (SINGLE SIDED ONLY)
LED EXIT SIGN – WEATHERPROOF (IP65) (SINGLE SIDED ONLY)
The VES 390/WP LED EXIT sign is ideal for outdoor and damp environments, such as coastal areas. With IP65 protection and constructed from a single molded piece, it ensures durability and reliability in challenging conditions.
Kategori :
1-10W, IP 65, IP Rating, Watt, SNI
Aplikasi :
Outdoor Area, Coastal Area, Laboratory, Hospitals, Factory, Warehouse
Warna :
-
Smooth White
Body
Injection Moulded from Polycarbonate
Diffuser
Injection Moulded from Polycarbonate with Sign
Mounting Bracket
Fabricated from Mild Steel
Wire
105°C Heat Resistance PVC Cable
Connector
Nylon 3 Way x 2.5mm2
Finishing
Smooth Finishes Diffuser and Housing
Mounting Type
Surface Wall
Indicator
Green
ALWAYS ON Charging, No fault
INDICATOR LIGHT OFF Operating on battery mode
Lamp
LED 2835 (4PCS)
Battery
Ni-Cd AA 3.6V 900mAh
Main Supply (V, Hz)
220~240V, 50/60Hz
Mode of Operation
Maintained
System Power (W)
2.9 W
System Current (A)
0.01 A
Power Factor
PF ≥ 0.8
Emergency Duration
2 Hours
Recharge Period
15 Hours
Max. Operating Temperature (ta)
40°C
IP Grade
IP 65
Classification
Class II
Recommended Mounting Height
2.3 m
| Model | Product Weight (Kg) | Carton Size (mm) | Gross Weight (Kg) | Quantity | ||
|---|---|---|---|---|---|---|
| L | W | H | ||||
| VES 390/WP | 1.03 Kg | 398 mm | 202 mm | 72 mm | 11.80 Kg | 10 pcs / Carton |
| Model | Base | Dimension | ||
|---|---|---|---|---|
| L | W | H | ||
| VES 390/WP/E | “Exit” Word Only | 392 mm | 66 mm | 189 mm |
| VES 390/WP/EL | “Exit” Word + Arrow to Left | 392 mm | 66 mm | 189 mm |
| VES 390/WP/ER | “Exit” Word + Arrow to Right | 392 mm | 66 mm | 189 mm |
| VES 390/WP/RM | Running Man Only | 392 mm | 66 mm | 189 mm |
| VES 390/WP/RML | Running Man + Arrow to Left | 392 mm | 66 mm | 189 mm |
| VES 390/WP/RMR | Running Man + Arrow to Right | 392 mm | 66 mm | 189 mm |
DTS 1: Data Sheet – VES 390/WP
523.36 KB
